Display Specifications
- Diagonal Dimension : 2.4 inch
- Resolution : 240(RGB)x320 pixel
- View Direction : 12 o'clock
- Touch Mode : Resistive
- Module Dimension : 42.7x60.3x3.8 mm
- Viewing Area : 36.7x48.9 mm
- Supply Voltage : 3.3 V
- Interface : 8/16 Bit MCU
- Luminance : ≥500 cd/m2
- Drive IC : ST7789V
- Operation Temperature : -20℃~70℃
- Storage Temperature : -30℃~80℃
Dimensions
Resources
- DM-TFT24-405
- Display Controller: ST7789V-V1.4
