Display Specifications
- Diagonal Dimension : 5.0 inch
- Resolution : 800x480 pixel
- View Direction : 12 o’clock
- Touch Mode : None
- Module Dimension : 120.70(H)x75.80(V)x4.15(D) mm
- Viewing Area : 108.00(H)x64.80(V) mm
- Supply Voltage : 3.3 V
- Interface : 16/18/24 bit RGB
- Luminance : 350 cd/m2
- Drive IC : ILI5960/ILI6122
- Operation Temperature : -20℃~70℃
- Storage Temperature : -30℃~80℃
Dimensions
Resources
- DM-TFT50-318
- Display Controller: ILI5960 / ILI6122
- No init code needed for this display panel
