0.7-inch Micro OLED Display Panel with 1920x1080 resolution and 3000nits brightness

Front View of 0.7-inch Micro OLED Display Panel

Top View of 0.7-inch Micro OLED Display Panel

Two 0.7-inch micro OLED display panels connected to a driver board

A single 0.7-inch micro OLED display panel connected to a driver board

0.7" Micro OLED 3000nits Display 1920x1080

SKU: DM-OLEDC070-661

$399.00

💹 Enjoy a 20% discount for orders over 500
📉 A 15% discount is available for orders ranging from 200 to 499
🎁 A 10% discount is available for orders ranging from 50 to 199
🎁 A 5% discount is available when ordering 10-49

Interested in customizing this product? Get in touch with us.

Order samples, immediate delivery.

Factory bulk lead time: 3 weeks.

0.7" Micro OLED 3000nits Display 1920x1080

$399.00

0.7" Micro OLED Display Module 1920x1080

Active Matrix Color OLED display integrating single crystal silicon transistors. Engineered for high-density optical systems, AR smart glasses, head-up displays (HUD), and precision medical viewfinders requiring maximum luminance in a compact form factor.

3000 Nits

Peak Luminance

10,000:1

Contrast Ratio

0.7-inch Micro OLED Display 1920x1080 Physical Dimensions

Product Specifications

Parameter	Specification
Display Technology	Active Matrix Color OLED
Effective Display Area	15.8mm × 8.99mm
Resolution	1920(RGB) × 1080 (6.22 million dots)
Color Depth	24-bit (16.7 million colors)
Interface	LVDS
Frame Rate	60Hz
Power Supply	1.8V, 10V, VCCP
Operating Temperature	-20℃ to +70℃
Storage Temperature	-30℃ to +80℃
Module Mass	1.3g

Electro-Optical Architecture

Pixel Density

Yields a total of 6.22 million sub-pixels, ensuring zero screen-door effect in near-eye optics.

Pixel Pitch: 8.23 μm

Color & Luminance Stability

sRGB gamut coverage. Integrated luminance temperature compensation circuit maintains stable 3000 nits output across thermal variations.

Scan Configuration

Hardware-level support for up/down and right/left scan direction selection. Native support for YCbCr/YPbPr format conversion.

Motion Blur: < 1ms

Hardware Integration Parameters

Designed for streamlined PCB integration. The module separates logic and high-voltage panel drives for optimal power efficiency.

Power Supply Architecture

VDD (Logic): 1.8V
VCI (Analog): 3.3V
VSP (Panel Drive): 10V
Power Saving (PS) mode supported via register mapping

LVDS Data Interface

Data transmission utilizes Low-Voltage Differential Signaling (LVDS) to minimize EMI and ensure signal integrity at high resolutions.

4-Lane Data

RXIN0± to RXIN3±

1-Lane Clock

CLKIN±

Optimized Industry Applications

Augmented Reality (AR)

3000 nits high-brightness output ensures clear visibility in outdoor or strong ambient light conditions.

Head-Up Displays (HUD)

3000 nits peak luminance ensures critical data overlay remains highly legible against bright daylight or direct sunlight backgrounds.

Medical Viewfinders

Precise 24-bit color depth required for accurate tissue rendering in endoscopic and surgical imaging.

Industrial Metrology

High contrast ratio (10,000:1) allows for sharp textual and crosshair overlays in measurement devices.

OEM Procurement & Documentation

We support deep hardware customization. Logistics configuration standardizes at 15 units per tray, 210 units per master carton.

Engineering teams can access complete pin descriptions, initialization codes, power sequence timing diagrams, and CAD models.

Download Official PDF Datasheet

Product FAQs

Key technical and purchasing guidance for product evaluation, integration planning, samples, and volume orders.

Need more help? Contact our technical team.

Are DM-OLEDC070-661 and DM-OLED071-682 the same screen?

Yes. DM-OLEDC070-661 and DM-OLED071-682 use the Sony ECX335SN-6 display. A previous homepage size entry was incorrect, so use the latest datasheet and mechanical drawing as the authoritative reference.

What interface and driver solution are required to connect DM-OLEDC070-661 to a Raspberry Pi board?

DM-OLEDC070-661 requires a compatible HDMI driver board when used with a Raspberry Pi. A Raspberry Pi Zero W can connect through its Micro-HDMI output using the appropriate Micro-HDMI-to-Mini-HDMI cable for the selected board.

Do you have STEP file drawing for the procured OLED?

Yes. STEP and Parasolid files are available for DM-OLEDC070-661 as “DM-OLEDC070-661.STEP” and “DM-OLEDC070-661.x_t.” Contact DisplayModule if the files are not listed on the product page.

Both DM-OLEDC070-661 and DM-OLED071-681 have same LVDS pinout; why can't DM-ADTTR-028-1 work?

The two displays cannot share the same adapter simply because their LVDS pinouts match. Their driver programs are different, so each display must be paired with the adapter and firmware intended for that model.
