2.56" High PPI 2K TFT Display 2160x2160 - MIPI
- 💹 Enjoy a 20% discount for orders over 500
- 📉 A 15% discount is available for orders ranging from 200 to 499
- 🎁 A 10% discount is available for orders ranging from 50 to 199
- 🎁 A 5% discount is available when ordering 10-49
Interested in customizing this product? Get in touch with us.
Order samples, immediate delivery.
Factory bulk lead time: 3 weeks.
Partager
2.56" High PPI 2K TFT Display 2160x2160 - MIPI
Prix de vente$99.00
2.56" High PPI 2K TFT Display 2160x2160 - MIPI
- 💹 Enjoy a 20% discount for orders over 500
- 📉 A 15% discount is available for orders ranging from 200 to 499
- 🎁 A 10% discount is available for orders ranging from 50 to 199
- 🎁 A 5% discount is available when ordering 10-49
2.56" 2160×2160 LTPS TFT Display Specifications
The 2.56-inch LTPS TFT LCD display features a 2160 × 2160 resolution with an impressive 1192 PPI pixel density. Equipped with FFS mode and advanced CPHY (MIPI 2-port + DSC) interface, this display supports 16.7 million colors and is ideal for VR, AR, and high-end wearable applications requiring compact size and high visual clarity.
| Parameter | Value | Unit |
|---|---|---|
| Size | 2.56 | inch |
| Display Mode | FFS | - |
| Resolution | 2160 × 2160 | pixels |
| Pixel Density | 1192 | ppi |
| Technical Type | LTPS | - |
| Active Area | 46.008 × 46.008 | mm |
| Module Size | 50.51 × 57.49 × 1.88 | mm |
| Display Colors | 16.7M | - |
| Interface | CPHY (MIPI 2-port + DSC) | - |
Mechanical Dimensions
Please refer to the mechanical drawing in the datasheet for detailed dimensions and integration planning.
Technical Resources
Download the datasheet for comprehensive specifications and integration guidelines.
