3.4" Round TFT Display 800x800 16.7M Colors - MIPI

SKU: DM-TFTR34-478
Prix de vente$44.90
  • 💹 Enjoy a 20% discount for orders over 500
  • 📉 A 15% discount is available for orders ranging from 200 to 499
  • 🎁 A 10% discount is available for orders ranging from 50 to 199
  • 🎁 A 5% discount is available when ordering 10-49

Interested in customizing this product? Get in touch with us.

Order samples, immediate delivery.

Factory bulk lead time: 3 weeks.

Type: panel

Partager
A 3.4-inch round screen showing a hot air balloon
3.4" Round TFT Display 800x800 16.7M Colors - MIPIpanel Prix de vente$44.90

3.4" 800×800 TFT Display Specifications

The 3.4-inch round TFT LCD module delivers a crisp 800 × 800 resolution with all-direction viewing, MIPI interface, and 350 cd/m² luminance. Powered by the SC7705 driver IC, it is ideal for portable devices, handheld instruments, and industrial controls requiring compact, high-resolution displays.

Parameter Value Unit
Diagonal Dimension 3.4 inch
Resolution 800 × 800 pixels
Viewing Direction All -
Touch Mode None -
Module Dimensions 96.95 × 94.9 × 2.3 mm
Viewing Area 87.6 × 87.6 mm
Supply Voltage 2.8 V
Interface MIPI -
Luminance 350 cd/m²
Driver IC SC7705 -
Operating Temperature -20 ~ 70 °C
Storage Temperature -30 ~ 80 °C

Mechanical Dimensions

Please refer to the following mechanical drawing for detailed measurements and mechanical design reference.

3.4 inch TFT LCD mechanical drawing

Technical Resources

Download datasheets and 3D model files for full technical details and mechanical integration.
