5.0" Round TFT Display 1080x1080 16M-colors Transmissive - MIPI DSI
- 💹 Enjoy a 20% discount for orders over 500
- 📉 A 15% discount is available for orders ranging from 200 to 499
- 🎁 A 10% discount is available for orders ranging from 50 to 199
- 🎁 A 5% discount is available when ordering 10-49
Interested in customizing this product? Get in touch with us.
Order samples, immediate delivery.
Factory bulk lead time: 3 weeks.
Partager
5.0" Round TFT Display 1080x1080 16M-colors Transmissive - MIPI DSI
Prix de vente$149.00
5.0" Round TFT Display 1080x1080 16M-colors Transmissive - MIPI DSI
- 💹 Enjoy a 20% discount for orders over 500
- 📉 A 15% discount is available for orders ranging from 200 to 499
- 🎁 A 10% discount is available for orders ranging from 50 to 199
- 🎁 A 5% discount is available when ordering 10-49
5.0" 1080×1080 Round TFT Display Specifications
This 5.0-inch Round TFT LCD delivers a crisp 1080 × 1080 resolution, 400 cd/m² luminance, and full viewing angles. With MIPI-DSI interface and compact 1.8 V supply, it is ideal for high-end embedded UIs, smart wearables, and interactive display systems requiring high pixel density in round format.
| Parameter | Value | Unit |
|---|---|---|
| Diagonal Dimension | 5.0 | inch |
| Resolution | 1080 × 1080 | pixels |
| Viewing Direction | All | - |
| Touch Mode | None | - |
| Module Dimensions | 136.531 × 132.208 × 1.98 | mm |
| Viewing Area | 127.008 × 127.008 | mm |
| Supply Voltage | 1.8 | V |
| Interface | MIPI-DSI | - |
| Luminance | 400 | cd/m² |
| Driver IC | HX8399C | - |
| Operating Temperature | -20 ~ 60 | °C |
| Storage Temperature | -30 ~ 75 | °C |
Mechanical Dimensions
