Select Guide

 Size Resolution Luminance（nits） Viewing angle Display Technology Interface Controller IC Part Number
1.08" 240*210 All IPS Transmissive TFT 4-SPI ST7789V2 DM-TFTR108-458
1.19" 240*240 12 All Transflective/TFT RGB / DM-TFTR119-464
1.22" 240*204 150
All 		Transmissive/TFT SPI ST7789H2 DM-TFTR122-465
1.22" 240*204 300
All 		TFT 4SPI ST7789V DM-TFTR122-475
1.28" 240*240 320 3wire-SPI(1 Lane or 2 Lane) GC9A01 DM-TFTR13-463
1.28" 240*240 350
All 		Transmissive/TFT SPI GC9A01 DM-TFTR128-466
1.28" 240*240
All 		Transmissive/TFT SPI GC9A01 DM-TFTR128-467
1.3" 240*240 300
All 		Transmissive TFT System Serial interface ST7789V DM-TFTR13-457
1.3" 240*240 3800
All 		TFT IPS GC9A01 DM-TFTR13-476
1.39" 454*454 350
All 		AMOLED MIPI/SPI RM69330 DM-OLED14R-678
1.39" 454*454 400 AMOLED MIPI/SPI ICNA3310 DM-OLEDR14-679
1.4" 454*454 MIPI/SPI RM69330 DM-OLED14R-677
2.0" 480*480 350
All 		Transmissive/TFT MIPI GC9503V DM-TFTR21-468
2.1" 480*480 250 TFT ST7701S DM-TFTR21-477
2.1" 480*480 300 TFT ST7701S DM-TFTR21-477-2
2.1" 480*480 350
All 		Transmissive/TFT MIPI-DSI HX8379-C DM-TFTR247-469
2.4" 480*480 400
All 		Normally white RGB HX8379-C DM-TFTR25-460
2.5" 480*480 TFT 3SPI + RGB ST7701S DM-TFT28-479
2.7" 800*800 Top:80,Bottom:80; Left/ Right:80

a-Si TFT,

Transmissive,

Normally black,IPS

 RGB ST7701S DM-TFTR20-461
3.0" 432 x 432 800 12 O'clock Transmissive/TFT MIPI ST7796SI DM-TFTR334-470
3.3" 320*320 750 All Transmissive/TFT MIPI 3 lane ILI9881C DM-TFTR34-471
3.4" 800*800 350 All TFT MIPI SC7705 DM-TFTR34-478
3.4" 800*800 350 Normally Black RGB HX8363-A DM-TFTR30-462
5.0" 1080*1080 400 All Normal white,IPS HX8399C DM-TFTR50-459
5.0" 1080*RGB*1080 All Transmissive/TFT MIPI-DSI HX8399C DM-TFTR50-472
