Mechanical Dimensions
0.39" 1024×768 Micro-OLED | Ultra-Bright 1800 cd/m²
This high-performance 0.39-inch Micro-OLED display module delivers exceptional 1024×768 resolution with ultra-fine 7.8μm pixel pitch, creating stunning visual clarity for near-eye applications. With a maximum brightness of 1800 cd/m² and outstanding contrast ratio exceeding 10,000:1, it provides vivid imagery even in bright environments.
Engineered with advanced AMOLED technology, this display offers true blacks, wide color gamut, and rapid response times under 2ms. The compact form factor and minimal power consumption make it ideal for portable and wearable devices requiring high-quality visual performance.
- Ultra-Compact Design: 0.39-inch active area with minimal bezel for space-constrained applications.
- High Efficiency: Low power consumption of 65mW at 60Hz refresh rate extends battery life.
- Wide Compatibility: Supports 24bit RGB and YCbCr signal formats for versatile integration.
- Premium Image Quality: 90% uniformity and 256 grayscale levels ensure consistent, detailed imagery.
| Parameter | Specification |
|---|---|
| Screen Size | 0.39 inch |
| Resolution | 1024 × 768 pixels |
| Pixel Size | 0.0078 × 0.0078 mm |
| Active Area | 8.1325 × 6.1779 mm |
| Pixel Arrangement | RGB Vertical Stripe |
| Grayscale | 256 levels |
| Uniformity | ≥ 90% |
| Contrast Ratio | >10,000:1 |
| Refresh Rate | 25 ~ 75 Hz |
| Video Format | 24bit-RGB / 8/16/24bit-YCbCr |
| Typical Luminance | 600 cd/m² |
| Max Luminance | 1800 cd/m² |
| Supply Voltage | 1.8V / 5.0V |
| Power Consumption | 65mW @ 60Hz / 54mW @ 25Hz |
| Color Coordinates | CIE-x: 0.31 ± 0.05, CIE-y: 0.33 ± 0.05 |
| Weight | 1 g |
We provide customized display solutions for businesses seeking to integrate high-performance Micro-OLED technology into their products. Our enterprise services include technical consultation, custom configurations, and volume manufacturing.
- Custom Integration: Tailored solutions for specific application requirements and form factors.
- Volume Pricing: Competitive wholesale rates for large quantity orders with flexible MOQs.
- Technical Support: Comprehensive engineering assistance throughout integration and production.
High-resolution near-eye displays for immersive augmented and virtual reality experiences with minimal latency.
Precision displays for surgical scopes, endoscopes, and diagnostic equipment requiring high contrast and clarity.
Ruggedized displays for weapon sights, night vision systems, and tactical goggles with superior performance in various lighting conditions.
Compatibility: This display module is compatible with standard interface protocols and can be integrated with various driver ICs and controllers. Operating temperature range of -20°C to 80°C ensures reliability across diverse environments.
Technical Documentation: Download complete datasheet for detailed specifications, pin definitions, and integration guidelines.
