10.4" IPS 1300nits Display 1024x768 4:3 - LVDS
Experience exceptional visual clarity with our 10.4-inch IPS display featuring 1300 nits high brightness and 1024×768 resolution. Engineered for demanding industrial environments with wide temperature tolerance and reliable LVDS interface.
This industrial-grade display module delivers crisp 4:3 aspect ratio visuals with IPS technology providing 178° wide viewing angles. The 1300 nits brightness ensures excellent visibility even in direct sunlight conditions.
- High Brightness IPS Panel: 1300 cd/m² luminance for outdoor and high-ambient light applications
- Wide Temperature Range: Operational from -30°C to 80°C for industrial reliability
- Compact Module Design: 230×180×10mm dimensions with 210×158mm viewing area
- Low Voltage Operation: 3.3V power supply for energy-efficient performance
| Parameter | Specification |
|---|---|
| Diagonal Dimension | 10.4 inch |
| Resolution | 1024×768 pixels |
| View Direction | - |
| Touch Mode | None |
| Module Dimension | 230×180×10 mm |
| Viewing Area | 210×158 mm |
| Supply Voltage | 3.3 V |
| Interface | LVDS |
| Luminance | 1300 cd/m² |
| Drive IC | - |
| Operation Temperature | -30°C to 80°C |
| Storage Temperature | -30°C to 80°C |
This display module is designed to work seamlessly with our HDMI to LVDS adapters for easy integration into various systems.
- Adapter Compatibility: Compatible with DM-ADTTR-018 (without transformer) for HDMI to LVDS conversion
- Standard LVDS Interface: 20-pin LVDS connector for universal compatibility
- Industrial Standards: Meets industrial display requirements for reliability and longevity
We provide customized display solutions for industrial and commercial applications with volume pricing and technical support.
- Custom Configurations: Tailored solutions for specific application requirements
- Volume Discounts: Competitive pricing for bulk orders and OEM projects
- Technical Support: Expert assistance for integration and implementation
High-brightness displays for HMI systems in manufacturing environments requiring reliable operation in extreme temperatures.
Crisp visualization for diagnostic devices and patient monitoring systems with wide viewing angles.
Rugged displays for vehicle systems and public information displays with sunlight-readable performance.
Technical Documentation: Complete specifications and integration guidelines available for download.
Resources: Download DM-TFT104-411 Datasheet
Dimensions
