2.1" Round TFT Display 480x480 CapacitiveWith touch
Sale price$49.90
2.1" Round TFT Display 480x480 Capacitive
- 💹 Enjoy a 20% discount for orders over 500
- 📉 A 15% discount is available for orders ranging from 200 to 499
- 🎁 A 10% discount is available for orders ranging from 50 to 199
- 🎁 A 5% discount is available when ordering 10-49
2.1" 480×480 TFT Display with Capacitive Touch Specifications
The 2.1-inch round TFT LCD display features a 480 × 480 resolution, capacitive touch support, and all-direction viewing. With a luminance of up to 350 cd/m² and powered by the ST7701S driver IC, this module is ideal for compact touchscreen interfaces in portable electronics, wearables, and control panels.
| Parameter | Value | Unit |
|---|---|---|
| Diagonal Dimension | 2.1 | inch |
| Resolution | 480 × 480 | pixels |
| Viewing Direction | All | - |
| Touch Mode | Capacitive | - |
| Module Dimensions | 48 × 32.2 × 3.2 | mm |
| Viewing Area | 26.64 × 26.64 | mm |
| Supply Voltage | 5.0 | V |
| Interface | - | - |
| Luminance | 300 / 350 | cd/m² |
| Driver IC | ST7701S | - |
| Operating Temperature | -20 ~ 60 | °C |
| Storage Temperature | -30 ~ 70 | °C |
Mechanical Dimensions
The following diagrams provide detailed measurements for enclosure and mechanical design integration.
Technical Resources
Download datasheets and 3D model files for complete technical specifications and design support.
