2.47" Round TFT Display 480x480 16.7M-colors - RGB
High-performance 2.47-inch circular TFT LCD display with 480×480 resolution and 16.7 million color capability. Designed for embedded applications requiring compact form factor and wide viewing angles. Features amorphous silicon TFT technology with HX8379-C driver IC for reliable operation in industrial environments.
The display utilizes normally black transmissive mode with 2-domain stripe pixel arrangement. With 400 cd/m² typical luminance and 1000:1 contrast ratio, it delivers crisp visuals even in bright environments. The circular design maximizes active area utilization while maintaining compact dimensions.
- Advanced Driver Technology: HX8379-C controller supports MIPI DSI interface with 2 data lanes for high-speed data transmission.
- Wide Viewing Angles: 85° typical viewing angle in all directions (3/6/9/12 o'clock positions) with consistent color performance.
- Low Power Operation: 80mW typical power consumption in normal mode, 260μW in standby mode for energy-efficient applications.
- Robust Construction: 0.4t glass substrate with industrial-grade components rated for -10°C to 60°C operation.
| Parameter | Specification |
|---|---|
| Display Type | a-Si TFT LCD, Transmissive |
| Display Mode | Normally Black |
| Diagonal Size | 2.47 inch |
| Resolution | 480 × 480 pixels |
| Pixel Pitch | 130.5 × 130.5 μm |
| Active Area | 62.64 × 62.64 mm (circular) |
| Module Dimensions | 69.19 × 71.74 × 2.45 mm |
| Luminance | 400 cd/m² (Typical) |
| Contrast Ratio | 1000:1 (Typical) |
| Viewing Angle | 85° (All directions, CR>10) |
| Color Gamut | 70% NTSC (Typical) |
| Interface | RGB with MIPI DSI (2 data lanes) |
| Supply Voltage | IOVCC: 1.8V, VCI: 3.3V |
| Operating Temperature | -10°C to 60°C |
| Storage Temperature | -30°C to 70°C |
| Driver IC | HX8379-C |
Customized display solutions for OEM and system integrators requiring reliable TFT displays for industrial applications. We support volume manufacturing with flexible configuration options.
- Bulk Order Programs: Volume pricing available for orders above 100 units with customized packaging and labeling options.
- Custom Configuration: Modified firmware, interface compatibility, and mechanical adaptation for specific application requirements.
- Technical Support: Comprehensive documentation and engineering support for integration and troubleshooting.
Patient monitoring equipment, portable diagnostic devices, and healthcare instrumentation requiring clear, reliable displays with wide viewing angles.
Human-machine interfaces for industrial control systems, automation equipment, and embedded computing with robust temperature tolerance.
Handheld test equipment, measurement devices, and field instruments benefiting from compact circular display format and low power consumption.
Compatibility Notes: Compatible with systems supporting MIPI DSI interface. Requires 1.8V I/O voltage and 3.3V analog supply. Operating frame rate: 60Hz typical with column inversion drive method.
Documentation: Download Complete Datasheet (PDF) | HX8379-C Driver IC Datasheet (PDF) | 3D Model (STEP)
Mechanical Dimensions
The diagram below provides accurate measurements for module integration and mechanical fitting.
