2.6" 320×432 TFT Display Specifications
The 2.6-inch TFT LCD offers 320 × 432 resolution, 500 cd/m² brightness, all-direction viewing, and wide interface support. With ILI9488 driver IC, this module is ideal for industrial control, handheld devices, and embedded systems operating in harsh temperature environments.
| Parameter | Value | Unit |
|---|---|---|
| Diagonal Dimension | 2.6 | inch |
| Resolution | 320 × 432 | pixels |
| Viewing Direction | All | - |
| Touch Mode | None | - |
| Module Dimensions | 46.76 × 65.85 × 2.6 | mm |
| Viewing Area | 39.84 × 53.78 | mm |
| Supply Voltage | 3.3 | V |
| Interface | 8/9/16/18/24-bit MCU, 3/4-SPI, 16/18/24-bit RGB | - |
| Luminance | 500 | cd/m² |
| Driver IC | ILI9488 | - |
| Operating Temperature | -30 ~ 85 | °C |
| Storage Temperature | -40 ~ 85 | °C |
Mechanical Dimensions
