Dimension
0.49" Micro OLEDoS Display 1920x1080 90Hz 3000nits - MIPI
Experience exceptional visual clarity with our 0.49-inch Micro OLED display, delivering ultra-high brightness of 3000 nits and Full HD resolution in a compact form factor. This advanced display technology offers superior image quality for professional and industrial applications.
This Micro OLED display module integrates driver circuitry and logic control, achieving minimal size, lightweight design, low power consumption, and exceptional resolution. The display supports full-color mode with 16.7 million colors for vibrant, accurate reproduction.
- High Pixel Density: Exceptional PPI for crystal-clear image quality
- Wide Operating Temperature: Performance from -20℃ to +70℃
- Low Power Consumption: Optimized for energy-efficient applications
- MIPI Interface: Standard interface for easy integration
| Parameter | Specification |
|---|---|
| Resolution | 1920(H) × 1080(V) |
| Active Area | 10.783mm × 6.065mm / 0.49" diagonal |
| Bezel Size | 15.68mm × 9.09mm × 1.5mm |
| Luminance | 3000 cd/m² typical |
| Contrast Ratio | 50,000:1 |
| Frame Rate | Max. 90Hz |
| Color | Full-color (16.7M colors) |
| Interface | MIPI D-PHY |
| Operating Temperature | -20℃ to +70℃ |
| Storage Temperature | -40℃ to +80℃ |
We offer customized display solutions for businesses seeking to integrate high-performance Micro OLED technology into their products. Our enterprise services include:
- Custom Configurations: Tailored display solutions for specific application requirements
- Bulk Order Programs: Competitive pricing for volume purchases and OEM partnerships
- Technical Support: Expert assistance for integration and implementation
- Long-term Supply Agreements: Reliable inventory management for production planning
Ideal for AR glasses and headsets requiring high brightness and compact form factors for immersive experiences.
Perfect for VR devices demanding high resolution and fast refresh rates for realistic virtual environments.
Essential for medical displays where accuracy, color fidelity, and high contrast are critical for diagnosis.
Suited for industrial applications requiring durable, high-visibility displays in various lighting conditions.
Documentation: Complete technical specifications, interface protocols, and integration guidelines available for developers and engineers.
Datasheet: Download complete technical documentation
Support: Our technical team provides comprehensive support for display integration, including interface configuration and power management optimization.
