0.5" Micro OLEDoS Display 1600x1200 120Hz 1000nits - MIPI
- 💹 Enjoy a 20% discount for orders over 500
- 📉 A 15% discount is available for orders ranging from 200 to 499
- 🎁 A 10% discount is available for orders ranging from 50 to 199
- 🎁 A 5% discount is available when ordering 10-49
Interested in customizing this product? Get in touch with us.
Order samples, immediate delivery.
Factory bulk lead time: 3 weeks.
0.5" Micro OLEDoS Display 1600x1200 120Hz 1000nits - MIPI
- 💹 Enjoy a 20% discount for orders over 500
- 📉 A 15% discount is available for orders ranging from 200 to 499
- 🎁 A 10% discount is available for orders ranging from 50 to 199
- 🎁 A 5% discount is available when ordering 10-49
Dimension
0.5" Micro OLEDoS Display 1600x1200 120Hz 1000nits - MIPI
This high-performance 0.5-inch Micro-OLED display delivers exceptional image quality with 1600×1200 resolution and up to 120Hz refresh rate. Featuring a compact form factor and low power consumption, it's engineered for advanced optical applications requiring high pixel density and superior contrast.
Built with single-crystal silicon transistor technology, this Micro-OLED panel integrates both driver and logic circuits, achieving small size, lightweight design, and minimal power consumption while maintaining high resolution performance.
- High Contrast Ratio: 100,000:1 typical contrast ratio for deep blacks and vibrant colors
- Wide Color Gamut: 90% DCI-P3 coverage with precise color reproduction
- Advanced Interface: MIPI D-PHY v1.1 with 1 port (4 lanes, 1.0Gbps/Lane) support
- Compression Support: Integrated VESA-DSC v1.1 decoder with 3:1 & 3.75:1 compression ratios
| Parameter | Specification |
|---|---|
| Resolution | 1600(H)×1200(V) |
| Number of Dots | 5.76M (1600×1200×3) |
| Pixel Size | 6.3μm×6.3μm |
| Display Area | 10.08mm×7.56mm |
| Luminance | 1000 cd/m² |
| Contrast Ratio | 100,000:1 typical |
| Uniformity | >85% |
| Power Consumption | 500mW typical |
| Gray Levels | 256 or 1024 |
| Interface | MIPI (1port D-PHY) |
| Frame Rate | 60Hz-120Hz |
| Operating Temperature | -20℃ to +70℃ |
| Storage Temperature | -40℃ to +80℃ |
We offer customized display solutions for businesses seeking to integrate high-performance Micro-OLED technology into their products. Our enterprise services include volume pricing, custom configurations, and technical support.
- Bulk Order Programs: Competitive pricing for volume purchases with flexible delivery options
- Custom Configurations: Tailored solutions for specific application requirements and form factors
- Technical Collaboration: Engineering support for seamless integration into your products
Ideal for AR/VR devices requiring high resolution, fast response time, and compact size for immersive experiences.
Professional photography and videography equipment benefiting from high brightness and contrast ratio.
Surgical displays and diagnostic equipment requiring precise color accuracy and high resolution.
Technical Notes: Display performance optimized for MIPI DSI v1.02 interface with support for 24-bit (16.7M colors) and 30-bit (1.07B colors) color depth. Includes scaling capabilities for various input resolutions.
Compatibility: Compatible with standard MIPI DPHY interfaces and supports I2C control protocol for configuration and settings adjustment.
Datasheet :DM-OLED050-1005
