0.96" IPS Display 160x80 - SPI
This 0.96-inch IPS display delivers a compact visual solution with an 80x160 pixel resolution, offering sharp text and graphics for space-constrained applications. With a luminance of 300 cd/m² and an all-view direction, it ensures clear visibility from various angles, making it ideal for portable devices.
Driven by the ST7735S IC, the display operates at 2.8V with a wide temperature range from -20℃ to 70℃, ensuring reliability in diverse environments. The module dimensions of 13.50x27.95x1.50 mm maximize space efficiency, while the 10.8x21.7 mm viewing area provides a balanced display surface.
- High Brightness: 300 cd/m² luminance enables clear viewing even in well-lit conditions, comparable to standard smartphone screens.
- Wide Viewing Angle: IPS technology supports all-view directions with consistent color accuracy.
- Low Power Operation: 2.8V supply voltage minimizes energy consumption for battery-powered devices.
- Robust Design: Operates in temperatures from -20℃ to 70℃, suitable for industrial and outdoor use.
| Parameter | Specification |
|---|---|
| Diagonal Dimension | 0.96 inch |
| Resolution | 80x160 pixel |
| View Direction | All View |
| Touch Mode | None |
| Module Dimension | 13.50x27.95x1.50 (Max) mm |
| Viewing Area | 10.8x21.7 mm |
| Supply Voltage | 2.8V |
| Interface | 4-wire SPI |
| Luminance | 300 cd/m² |
| Drive IC | ST7735S |
| Operation Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
We provide tailored display solutions for businesses, including custom configurations and bulk ordering options to meet specific project requirements.
- Custom Orders: Modify display parameters such as connector types or firmware for specialized applications.
- Bulk Pricing: Volume discounts for orders above 100 units, with logistics support for global shipping.
Ideal for smartwatches and fitness trackers, where the 0.96-inch size and low power consumption extend battery life.
Used in sensors and smart home controls, providing clear status displays with SPI interface simplicity.
Suited for control panels and instruments, leveraging the wide temperature range and robust build.
Compatibility: The 4-wire SPI interface ensures easy integration with common microcontrollers like Arduino, ESP32, and STM32. No touch functionality simplifies driver development.
Documentation: Access detailed datasheets and driver information for seamless implementation.
Downloads: DM-TFT096-396 Datasheet | ST7735S Driver IC Documentation | DM-TFT096-396 Code Examples
