240x64 LCD Graphic 5.46" - MCU
Professional-grade 240x64 pixel graphic LCD module featuring RA6963 controller with full T6963C compatibility. Designed for industrial applications requiring reliable text and graphics display capabilities.
The module integrates RA6963 controller IC supporting maximum 64KB external display RAM with built-in 256-word CGROM. Features include mixed text/graphic display modes, cursor control, and various attribute functions like reverse display and blinking.
- High Compatibility: Fully compatible with T6963C controllers, ensuring easy migration from existing designs
- Flexible Display Modes: Supports OR, EXOR, AND logical operations between text and graphics layers
- Wide Temperature Range: Operates reliably from -20°C to +70°C for industrial environments
- Multiple Font Sizes: Supports 5×8, 6×8, 7×8, and 8×8 pixel fonts via hardware/software selection
| Parameter | Specification |
|---|---|
| Display Type | FSTN Positive, Transflective |
| Resolution | 240 × 64 dots |
| Module Dimensions | 180.0 × 65.0 × 12.3(MAX) mm |
| Controller IC | RA6963 |
| Interface | Parallel MPU Interface (8080 compatible) |
| Power Supply | 5.0V DC ±10% |
| Operating Current | 26mA typical @ 5.0V |
| Backlight | White LED (3.4-3.6V, 80-100mA) |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -30°C to +80°C |
| Weight | 145.2 grams |
Compact form factor optimized for space-constrained applications with precise mechanical specifications.
Customized display solutions for industrial and commercial applications with volume pricing and technical support.
- Bulk Order Discounts: Competitive pricing for volume purchases with flexible payment terms
- Custom Configuration: Modified pinouts, connector types, and display parameters available
- Technical Support: Dedicated engineering support for integration and troubleshooting
- Long-term Supply: Guaranteed component availability for production lifecycle management
Machine interfaces, process monitoring systems, and equipment status displays requiring reliable operation in harsh environments.
Patient monitoring equipment, diagnostic instruments, and medical consoles with clear text/graphics display.
Electronic test equipment, laboratory instruments, and data acquisition systems needing graphical data presentation.
Seamless integration with popular microcontroller platforms and development environments.
- MPU Interface: Direct connection to 8080-series microprocessors with 8-bit parallel data bus
- Software Libraries: Available drivers for Arduino, Raspberry Pi, and embedded Linux platforms
- Development Tools: Compatible with common embedded development environments and debuggers
- Protocol Support: Standard parallel interface with minimal external components required
Documentation: Complete technical specifications, application notes, and design guidelines available for download.
Resources: DM-LCD24064-468 Datasheet | DM-LCD24064-469 Datasheet | RA6963 Controller Datasheet
