3.5" IPS High Brightness Display 320x240 920nits - RGB
Professional-grade 3.5-inch IPS display delivering exceptional 920 nits brightness for high-visibility applications. Featuring 320(RGB)×240 resolution with true 24-bit RGB interface for vibrant color reproduction.
Engineered with advanced IPS technology, this display maintains consistent color and contrast from any viewing angle. The 920 nits brightness ensures clear visibility even in direct sunlight conditions, making it ideal for outdoor and industrial applications.
- High-Brightness IPS Panel: 920 cd/m² luminance with wide 160° viewing angles for optimal visibility in bright environments.
- 24-bit True Color Interface: Supports 16.7 million colors with precise RGB data input for accurate color reproduction.
- Rugged Temperature Range: Operates reliably from -30℃ to 85℃, suitable for harsh industrial environments.
- Compact Form Factor: 76.9×63.9×3.17mm module size with 70.08×52.56mm active display area.
| Parameter | Specification |
|---|---|
| Diagonal Size | 3.5 inch |
| Resolution | 320(RGB) × 240 pixels |
| Viewing Direction | All Directions |
| Touch Function | None |
| Module Dimensions | 76.9 × 63.9 × 3.17 mm |
| Active Area | 70.08 × 52.56 mm |
| Supply Voltage | 3.3 V |
| Interface | 24-bit RGB |
| Luminance | 920 cd/m² |
| Drive IC | ST7272A |
| Operating Temperature | -30℃ to 85℃ |
| Storage Temperature | -40℃ to 85℃ |
We provide customized display solutions for industrial and commercial applications with volume pricing and technical support.
- Bulk Order Discounts: Competitive pricing for OEM and ODM projects with minimum order quantities.
- Custom Configuration: Tailored solutions including special bonding, connector types, and mechanical modifications.
-
Technical Support: Dedicated engineering support for integration and application development. Industry ApplicationsINDUSTRIAL HMIHigh-brightness display for factory automation, process control systems, and industrial equipment interfaces requiring sunlight readability.
MEDICAL DEVICESReliable display solution for medical monitoring equipment, diagnostic tools, and portable medical devices requiring consistent performance.
OUTDOOR EQUIPMENTWeather-resistant display for outdoor kiosks, agricultural machinery, and transportation systems operating in direct sunlight.
Technical ResourcesTechnical Documentation: Complete datasheets and application notes available for download.
Resources: Product Datasheet | ST7272A Controller Documentation
Dimensions Reference:
Dimensions
