6" Flexible AMOLED Display 1440x2880
Experience exceptional visual clarity with our 6-inch flexible AMOLED display featuring WQHD+ resolution (1440 × 2880 pixels). This advanced display module combines cutting-edge AMOLED technology with capacitive touch functionality for superior mobile viewing experiences.
This high-performance display module features MIPI-DSI 4-lane interface with BTB connection, ensuring reliable data transmission and easy integration. The panel delivers wide viewing angles with excellent color consistency across all directions.
- High Contrast Ratio: 90,000:1 typical (CPK > 1.33) for deep blacks and vibrant colors
- High Brightness: 450 cd/m² normal mode with HBM support up to 600 cd/m²
- Touch Technology: Advanced capacitive touch with multi-point support
- Environmental Compliance: Meets RoHS and REACH environmental standards
| Parameter | Specification |
|---|---|
| Active Area | 68.04 × 136.08 mm |
| Outline Dimensions | 75.2 × 147 mm |
| Pixel Density | 537 PPI |
| Viewing Direction | All directions |
| Interface | MIPI-DSI 4 lanes |
| Connection Type | BTB Connector |
| Touch Technology | Capacitive touch panel |
| Frame Rate | 60Hz |
We offer customized display solutions for businesses seeking high-quality AMOLED technology with flexible integration options.
- Custom Configurations: Tailored display solutions to meet specific product requirements
- Volume Pricing: Competitive wholesale pricing for large quantity orders
- Technical Support: Comprehensive engineering support for integration and optimization
Premium mobile devices requiring high-resolution displays with excellent color reproduction and power efficiency.
Rugged devices and industrial controls benefiting from wide viewing angles and high brightness capabilities.
Medical equipment requiring precise color accuracy and high contrast for diagnostic applications.
Compatibility: Compatible with major mobile platforms and operating systems. Supports standard MIPI-DSI interface for easy integration.
Environmental Specifications: Operating temperature range of -20°C to +70°C with storage temperature from -30°C to +80°C.
Documentation: DM-OLED60-697
