7" TFT Display 1280x800 - LVDS 40 Pin
Professional-grade 7-inch TFT LCD display featuring 1280×800 WXGA resolution with advanced a-Si technology and LVDS interface. Designed for industrial applications requiring high reliability and excellent optical performance.
Engineered with SFT (Super Fine TFT) technology and normally black mode, this display delivers 800:1 contrast ratio with 88° viewing angles across all directions. The compact 161.0×107.0×3.35mm design integrates seamlessly into space-constrained applications.
- High Reliability: Operating temperature range of -20°C to +70°C with industrial-grade component selection
- Advanced Backlight: 21-LED system providing uniform illumination with 30,000-hour lifespan
- Industrial Connector: Molex 54132-4062 connector ensuring secure LVDS signal transmission
- Power Management: Optimized power sequencing with VDD (3.3V), AVDD (11V), VGH (18V), and VGL (-6.8V) voltage rails
| Parameter | Specification |
|---|---|
| Display Size | 7.0 inch |
| Active Area | 149.76 × 93.60 mm |
| Pixel Pitch | 0.117 × 0.117 mm |
| Resolution | 1280 (RGB) × 800 |
| Display Mode | SFT with Normally Black |
| Contrast Ratio | 800:1 (Typical) |
| Viewing Angles | 88° (All directions, CR≥10) |
| Response Time | 35 ms (Typical) |
| LCM Dimensions | 161.0 × 107.0 × 3.35 mm |
| Weight | 120 g (Typical) |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -30°C to +80°C |
| Interface | LVDS 40-Pin |
| Connector Type | Molex 54132-4062 |
| LED Quantity | 21 LEDs |
| Driver IC | 3 × ST5821C + 1 × ST5084C |
| Power Supply | Min | Typ | Max | Unit |
|---|---|---|---|---|
| VDD (Digital) | 3.0 | 3.3 | 3.6 | V |
| AVDD (Analog) | 10.5 | 11.0 | 11.5 | V |
| VGH (Gate On) | 17.5 | 18.0 | 18.5 | V |
| VGL (Gate Off) | -7.1 | -6.8 | -6.5 | V |
| LED Forward Current | - | 140 | - | mA |
Custom display solutions for industrial and commercial applications with volume pricing and technical support.
- Bulk Order Programs: Volume discounts available for orders exceeding 72 units with flexible delivery scheduling
- Custom Modifications: Optional modifications including touch panel integration, extended temperature range, and custom firmware
-
Technical Support: Engineering support for integration challenges and application-specific requirements Industry ApplicationsINDUSTRIAL CONTROLHMI panels for factory automation, process control systems, and monitoring equipment requiring reliable operation in harsh environments.
MEDICAL EQUIPMENTPatient monitoring devices, diagnostic equipment, and portable medical instruments with clear visualization needs.
PORTABLE DEVICESHandheld terminals, portable test instruments, and mobile computing devices requiring compact, high-resolution displays.
Technical ResourcesTechnical Notes: Display requires proper power sequencing: VDD → AVDD → VGL → VGH with 5ms stabilization before signal input. LVDS clock frequency supports 62.6-78.1 MHz range.
Documentation: Download Complete Technical Datasheet (PDF)
Packaging SpecificationsItem Material Dimensions Quantity Display Module - 161.0×107.0×3.35mm 72 units/tray Tray PET 485×330×15.3mm 21 trays/box Inner Box Corrugated Paper 520×345×74mm 3 boxes/carton Master Carton Corrugated Paper 544×365×250mm 1 carton Mechanical Dimensions
Refer to the diagram below for module outline and installation envelope, including frame and thickness.
