8.0" 16.7M Colors TFT Display 800x600

Regular price $69.00
Shipping calculated at checkout.
SKU: DM-TFT800-508
8.0
$69.00

Payment and security

  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa

8" 800×600 TFT LCD Display Specifications

This 8-inch TFT LCD display features an 800×600 resolution with RGB vertical stripe pixel layout, anti-glare surface, and normally white mode. Designed for industrial and embedded systems, it includes edge-side LED backlight and operates reliably across a wide temperature range.

Parameter Value Unit
Screen Size 8.0 inch
Active Area 162.0 × 121.5 mm
Number of Pixels 800 × 600 pixels
Pixel Pitch 67.5 × 202.5 μm
Pixel Arrangement RGB Vertical Stripe -
Display Colors 16.7M colors
Display Mode Normally White -
Outline Dimensions 183.0 × 141.0 × 5.6 mm
Surface Treatment Anti-glare -
Backlight Edge Side, 1-LED Lighting Bar -
Operating Temperature -20 ~ 70 °C
Storage Temperature -30 ~ 80 °C

Mechanical Dimensions

See the mechanical drawing below for installation fit and structural integration details.

8 inch 800x600 TFT LCD mechanical drawing

Technical Resources

Download the datasheet for full mechanical, electrical, and optical specifications for the DM-TFT800-508 module.
