2.8" TFT Display 240X400 Transflective - MCU, SPI, RGB

Regular price $39.90
Shipping calculated at checkout.
SKU: DM-TFT28-444
2.8 inch Transflective TFT Display Panel with 240x400 resolution, utilizing MCU, SPI, and RGB interfaces
$39.90
Default Title

Payment and security

  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa

Display Specifications

  • Diagonal Dimension : 2.8 inch
  • Resolution : 240(RGB) x 400 pixel
  • View Direction : 5 O’clock
  • Touch Mode : None
  • Module Dimension : 44 x 72.5 x 2.6 mm
  • Viewing Area : 36.72(H) *61.2(V) mm
  • Supply Voltage : 2.8 V
  • Interface : 8/9/16/18Bit MCU Interface,3/4SPI+16/18Bit RGB Interface,3-line/4-line Serial Interface
  • Luminance : 120 cd/m2
  • Drive IC : ILI9327
  • Operation Temperature : -20℃~70℃
  • Storage Temperature : -30℃~80℃

Dimensions

Resources
