2.0" TFT Display 320x240 Transflective Resistive - MCU, SPI, RGB
2.0" TFT Display 320x240 Transflective Resistive - MCU, SPI, RGB
SKU:DM-TFT20-438
Regular price
$34.90 USD
Regular price
Sale price
$34.90 USD
Unit price
/
per
1 pcs | original price |
5 pcs | 8% off |
10 pcs | 10% off |
Shipping
Shipping
Standard and expedited shipping available, free expedited shipping over $600. Lenrn more
Easy Returns
Easy Returns
No need to worry about buying products that don't fit your design, we offer a 30-day no-questions-asked return service.
More Order, More Save
More Order, More Save
The higher the quantity ordered, the greater the discount, so contact us for the discount price! Contact us
Share
Display Specifications
- Diagonal Dimension : 2.0 inch
- Resolution : 320(RGB) x 240 pixel
- View Direction : Wide angle
- Touch Mode : None
- Module Dimension : 46.5 x 41.56 x3.9 mm
- Viewing Area : 40.80(H)*30.60(V) mm
- Supply Voltage : 2.8/3.3 V
- Interface : 8/9/16/18Bit MCU,3/4SPI+16/18Bit RGB Interface,3-line/4-line Serial
- Luminance : 280 cd/m2
- Drive IC : ILI9342C
- Operation Temperature : -20℃~70℃
- Storage Temperature : -30℃~80℃
